Operating Weight

15,400

kg

per products.csv

Drive Type

6×4 (Front Wheel Steering + Tandem Drive Axles)

—

per CSV

Overall Dimension (L × W × H)

~8,900 × 2,600 × 3,300

mm

Reference for same-class platform *

Wheelbase

~6,000

mm

Reference value *

Minimum Ground Clearance

~400

mm

Reference value *

Max Travel Speed

~40

km/h

Reference value *

Maximum Traction Force

~85

kN

Reference value *

Model

Caterpillar C7.1 (per CSV)

Rated Power

160 kW (per CSV; approx. 215 hp)

Displacement

7.01 L

Max Torque

~900 N·m (per industry document) *

Emission Standard

Tier 3 / China National Stage III

Fuel Tank Capacity

~380 L (common value for same class) *

Transmission

Hydro-mechanical Transmission, Power Shift (Reference) *

Gears

Multi-speed Forward / Reverse (F6/R6 class) *

Drive Axle

Tandem Drive Axle (Middle & Rear)

Axle Load Distribution

Front Axle ~30% / Rear Axle ~70% (common value for same class) *

Blade Length

14 ft (~4,270 mm, per CSV)

Blade Height

~610 mm (common value for same class) *

Blade Rotation

360° Rotation + Hydraulic Side Shift (Reference) *

Max Lift Height / Blade Depth

~450 / ~500 mm (common value for same class) *

Blade Angle Adjustment

Hydraulic Adjustable (Forward / Rearward Pitch)

Rear Optional Attachment

Ripper / Scarifier
