Operating Weight

17,950

kg

per products.csv

Overall Dimension (L × W × H)

~5,500 × 3,450 × 3,200

mm

Reference for same-class platform *

Travel Mode

Mechanical Transmission, Crawler Type

—

per CSV (Mechanical)

Track Shoe Width

~560

mm

Reference value *

Ground Pressure

~0.07

MPa

Reference value *

Travel Speed (Forward)

~0–11

km/h

Multi-speed, reference value *

Maximum Traction Force

~300

kN

Reference for same-class platform *

Gradeability

~30° (approx. 58%)

—

Reference value *

Model

Cummins NTA855 (Cummins, per CSV)

Rated Power

162 kW (per CSV)

Displacement

14.0 L (855 in³ class)

Max Torque

~1,200 N·m (per industry document) *

Emission Standard

Tier 3 / China National Stage III

Fuel Tank Capacity

~300 L (common value for same class) *

Transmission

Mechanical / Hydro-mechanical Transmission, Multi-speed Power Shift (Reference) *

Final Drive

Planetary Gear Final Reduction + Wet Steering Clutch (Reference) *

Brake

Wet Multi-disc Brake

Chassis

Reinforced Sealed Tracks, Track Guard (Mining Configuration)

Blade Type

Straight Blade / Semi-U Blade (Optional by Working Condition)

Blade Width

~3,400 mm (common value for same class) *

Blade Height

~1,150 mm (common value for same class) *

Blade Capacity

~3.5–4.5 m³ (depends on blade type) *

Max Lift Height / Cutting Depth

~1,000 / ~500 mm (Reference) *

Rear Optional Attachment

Single / Triple Shank Ripper
