Operating Weight

17,500

kg

per products.csv

Rated Load Capacity

5,000

kg

Reference for same-class platform *

Standard Bucket Capacity

3.0

m³

per CSV

Overall Dimension (L × W × H)

~8,100 × 3,000 × 3,450

mm

Reference for same-class platform *

Wheelbase

~3,300

mm

Reference value *

Drive Type

Articulated Frame, 4WD

—

per CSV (Articulated)

Maximum Breakout Force

≥170

kN

Reference value *

Max Travel Speed

~38

km/h

Reference value *

Model

Cummins 6LTAA9.3 (Cummins, per CSV)

Rated Power

162 kW (per CSV)

Displacement

9.3 L

Max Torque

~1,000 N·m (per industry document) *

Emission Standard

Tier 3 / China National Stage III

Fuel Tank Capacity

~250 L (common value for same class) *

Transmission

Planetary Power-shift Transmission (Reference) *

Gears

Multiple Forward / Reverse Gears

Axles

Front & Rear Heavy-duty Drive Axles, Wet Brakes (Reference) *

Steering

Articulated Steering (Steering Angle ~35–40°) *
