Transmission & Brakes

Gearbox: Torque converter + power shift (hydraulic type); dry clutch manual (economic type）

Drive axle: Integral drive axle, differential is standard equipment

Braking: service braking (hydraulic servo) + mechanical parking brake

Electrical: 12 V / 24 V (according to configuration）

Hydraulic System

Working pressure: approx. 17 MPa (reference）

Oil pump: gear pump, with priority unloading

Multi-way valve: monoblock type, 3-4 sections optional (fork/side shift/attachment

Mast & Attachments

Standard lifting height: 3000 mm; container version 4500 mm (2-stage/3-stage full-free mast can be optionally up to 6000 mm

Side shifter: standard configuration option (±100 mm class, reference）

Optional attachments: clamp, paper roll clamp, adjustable fork, etc.

The gantry design is suitable for container packing operations (low headroom, forward operation vision

Operator Compartment

Open type / Semi-enclosed type / Fully enclosed type are optional

Safety belt + adjustable seats; dashboard with integrated warning lights

Rearview mirror, reverse buzzer, LED work light (optional）
