Travel speed

Approx. 20 / 21 km/h

Lift speed

Approx. 400 / 450 mm/s

Lowering speed

Approx. 400 / 450 mm/s

Gradeability

Approximately 18%

Model (Reference for European version)

Deutz TCD 3.6 L04 (European version Stage V); other export markets are equipped with domestic or imported diesel engines according to regional configurations

Type

Inline 4-cylinder, turbocharged intercooled diesel engine (European version）

Displacement

3.6 L（Deutz TCD 3.6）

Rated power

Approximately 55.4 kW (European version specification, reference）

Emission

Stage V (European Version) / Tier 3 or according to the export region

Cooling system

forced water cooling

Working pressure

Approx. 19 MPa (Reference）

Pump

gear pump, priority unloading energy-saving circuit

Control valve

Integral multi-way valve + overload protection

Front

8.25-15-14PR（Pneumatic tires; convertible to solid tires.）

Rear

7.00-12-12PR

Overall length w/ forks

Approx. 4700 mm

Overall width

Approx. 1450 mm

Mast lowered height

Approx. 2500 mm

Overhead guard height

Approx. 2400 mm

Wheelbase

Approx. 2200 mm

Turning radius

Approx. 3300 mm

Ground clearance

Approx. 150 mm
