Travel speed

Approx. 20 / 21 km/h

Lift speed

Approx. 450 / 500 mm/s

Lowering speed

Approx. 450 / 550 mm/s

Gradeability

about 20%

Max drawbar pull

Approximately 18 kN

Model (common configurations, reference）

Domestic 4-cylinder diesel engines such as Xinchai 4D27G31; for export models, Isuzu is optional / configured according to regional emission standards

Type

Inline 4-cylinder, four-stroke water-cooled diesel engine

Displacement

Approx. 2.67 L

Rated power

Approx. 36.8 kW @ 2500 rpm (reference）

Emission

Tier 3 / Stage IIIA (depending on the export region, can be equipped with DPF/DOC）

Cooling system

forced water cooling

Working pressure

Approximately 17.5 MPa (reference）

Pump

Gear pump (multiple, priority unloading）

Control valve

Integral multi-way directional control valve with safety overflow

Hydraulic oil tank capacity

According to factory configuration (approx. 40–60 L class）

Front

28×9-15-12PR（Pneumatic tires; interchangeable solid tires）

Rear

6.50-10-10PR

Overall length w/ forks

Approx. 3750 mm

Overall width

Approx. 1225 mm

Mast lowered height

Approx. 2070 mm

Overhead guard height

Approx. 2140 mm

Wheelbase

Approx. 1700 mm

Front overhang / Rear overhang

Factory-allocated

Turning radius

Approx. 2400 mm

Ground clearance

Approx. 120 mm
