Right Hand Drive 12 Wheel 8X4 Tipper Truck

Sinotruk Tipper Truck Engine
Make: Sinotruk
Diesel: 4-stroke direct injection Diesel engine
Engine model: WD615.47
6-cylinder in-line with water cooling, turbo-charging and inter cooling
Maximum output:371hp(273KW)at 2200 rpm
Maximum torque: 1500 Nm at 1600 rpm
Number of cylinder :6

SEND INQUIRY NOW

Product parameters

Chassis	ZZ3317N3567
Engine	Make: Sinotruk
	Diesel: 4-stroke direct injection Diesel engine
	Engine model: WD615.47
	6-cylinder in-line with water cooling, turbo-charging and inter cooling
	Maximum output:371hp(273KW)at 2200 rpm
	Maximum torque: 1500 Nm at 1600 rpm
	Number of cylinder :6
Clutch	430,Single-plate dry clutch, hydraulically operating with air assistance
Transmission	SinoTruk HW19710 , 10 forward & 2 reverse
Transmission	Max.toque:1900Nm
Front Axle	HF9 Max.Loading: 9000Kgsx2
Rear Axle	HC16 Max Loading:16000Kgs x2
Steering	ZF Power Steering and Left Hand Driving
Brakes	Service brake: dual circuit compressed air brake
	Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
	Auxiliary brake: engine exhaust valve brake
Wheels & Tyres	Tyre: 12.00R20(Radial) ，One spare Tyre
Cab	HW 76 Standard Cab. Left hand drive.
Cab	With two seats, with one sleeper ,with A/C.70° hydraulically tillable to the front as attached photo for ref.
Color&Logo	According customer’s Requirement
Max.Speed	90 Km/h
Hydraulic cylinder	Front Tipping-Eurik brand
Dimensions in mm	Wheel base 1800+3500+1350
	Front gauge 2022
	Rear gauge 1830
	Front overhang 1500
	Rear overhang 2357
	Approach angle(°) 16
	Departure angle(°) 18
	Overall dimension(L x W x H mm) 10980×2500×3584mm
Quality utilization coefficient	1.04
Weight in kg	Kerb weight 13900
Weight in kg	Gross vehicle weight 50000
Body	Q235 Rectangle normal body
	Side:Floor :6mm:8mm
	Overall dimension of Body(L x W x H mm) 7400x2300x1500
