Operating Weight

17,000

kg

Actual configuration for Yimao export case; CSV calibrated 17,500 kg

Rated Load Capacity

5,000

kg

Case confirmed

Standard Bucket Capacity

3.0

m³

Case confirmed

Overall Dimensions (L × W × H)

~8,200 × 3,000 × 3,480

mm

Reference value (common outline for 5t platform) *

Wheelbase

~3,250

mm

Reference value *

Drive Type

Articulated Frame, 4WD

—

Articulation steering angle ~35°

Maximum Breakout Force

≥170

kN

Case confirmed

Model

Weichai WD10G220E23

Rated Power

162 kW @ ~2000 rpm

Displacement

9.7 L

Emission Standard

China Stage III / EU Stage IIIA (Case: China III / EU Stage IIIA)

Fuel Tank Capacity

~270 L (common value for same platform) *

Transmission

Planetary Power-shift Transmission (Fixed-shaft / Planetary optional)

Gears

Forward 2–4 / Reverse 2–4

Max Travel Speed

~38 km/h (Reference value) *

Axles

Front & Rear Heavy-duty Drive Axles, Wet Brakes
