Model

Weichai WD10G220E23 (per Changlin public documentation)

Type

Inline 6-cylinder, 4-stroke, water-cooled, turbocharged diesel engine

Rated Power

162 kW @ 2200 rpm (reference)

Emission Standard

Depends on destination market (China Stage III / Non-road Tier standard)

Fuel Tank Capacity

Approx. 230 L (reference)

Working Hydraulic System Pressure

Approx. 18 MPa (reference)

Lift Time

Approx. 6 s (reference)

Total Cycle Time (Lift + Dump + Lower)

Approx. 11–12 s (reference)

Bucket Breakout Force

Approx. 160 kN (reference)

Hydraulic Pump

Gear Pump / Dual-pump Confluence (subject to configuration)

Tyres

23.5-25-16PR (Off-road tire, reference)

Overall Length (Bucket lowered)

Approx. 8100 mm

Overall Width

Approx. 3000 mm

Overall Height (To cabin top)

Approx. 3400 mm

Wheelbase

Approx. 3300 mm

Track Width

Approx. 2200 mm

Minimum Ground Clearance

Approx. 450 mm

Bucket Width

Approx. 3000 mm (reference)
