Operating weight

17,500

kg

CSV

Rated load

5,000

kg

5t class (CSV standard)

Bucket capacity

3.0

m³

CSV; 2.7–3.5 m³ options available based on material

Drive type

4WD (four-wheel drive, articulated steering)

—

CSV

Dump height (45° dump angle)

~3,050

mm

Reference value

Dump reach

~1,080

mm

Reference value

Model

Weichai WD10G220E23

CSV

Type

Inline-6, four-stroke, water-cooled, turbocharged diesel engine

—

Rated power

162 kW @ 2,200 rpm

CSV

Displacement

9.7 L

Reference value

Maximum torque

~900 N·m @ 1,400 rpm

Reference value

Emission standards

Reference value

Fuel tank capacity

~230 L

Reference value

Working hydraulic system pressure

~18 MPa

Reference value

Sum of three operations (lifting + unloading + lowering)

~11.5 s

Reference value

Bucket breakout force

~168 kN

Reference value

Tipping load (full turn)

~108 kN（约 11,000 kg）

Reference value

Lifting time

~6 s

Reference value

Overall length（Lay the bucket flat.）

~8,250

mm

Overall width

~3,000

mm

Overall height（Up to the roof of the cab）

~3,430

mm

Wheelbase

~3,300

mm

Minimum ground clearance

~450

mm

Tire specifications

23.5-25-16PR（Construction machinery tires）

—
